ECG-32B

02 Details

• 4.3 inch 800×480 color TFT LCD to display ECG trace,diagnosis,setting menu operating status
• Multiple printout format of 3/2 channel,3/2+1 channel,3/3 channel,3/3+1 channel
• Simultaneous 12 lead acquisition
• Automatic measurement and interpretation of ECG parameters
• Unique system for menu setting and patient info management
• Instantaneous preview of waveforms data report before printing
• Automatic arrhythmia detection and recording
• Sleeping mode to save energy and extend LCD life
• LAN,USB port supporting data transmission to PC
• Single channel 60s compressed record
• Rhythm analysis with R-R histogram and trend chart
• High reliability with EMG filter of 25/35/45/75/100Hz(-3dB)
• Built in rechargeable Lithium battery supporting 250 exams
• CMRR of 100dB and Polarizing voltage of +600 mV
• 200 exams to be stored in memory for recall and duplication
• Paper size of 80mmx20m,roller type/Z-folding
